Main Features

  • Launched in 2016
  • Base Frequency: 350 MHz
  • Boost Frequency: 1000 MHz
  • Memory Size: System Shared
  • Memory Type: System Shared
  • Fabrication Process: 14 nm++

HD Graphics 630 Overview

HD Graphics 630 HD Graphics 630

The HD Graphics 630 is a Integrated solution by Intel, launched in Aug 30th, 2016. Built on the 14 nm++ process, and based on the Kaby Lake GT2 graphics processor, the device supports Direct X: 12 . This ensures that all modern games will run on HD Graphics 630. It features 350 MHz base clock and can be boosted up to 1000 MHz. With a power draw rated at 15 W maximum, it is connected to the system using a Ring Bus interface.

HD Graphics 630 is a member of Intel's HD Graphics (Kaby Lake) series of GPUs. Below you can find the latest models from this series.

Intel HD Graphics (Kaby Lake) Series History
Model Release Date Fabrication Process Performance
HD Graphics 610
Compare
August 2016 14 nm++ 201.6 GFLOPS
HD Graphics 630
August 2016 14 nm++ 384.0 GFLOPS

PERFORMANCE

FLOPS

FLOPS is commonly used for measuring GPU performance in 32-bit floating-point operations, essential for scientific computing, data analysis, machine learning, and graphics tasks. A higher value indicates faster and more complex calculations, vital for scientific research, simulations, and high-performance computing.

HD Graphics 630 has nearly top performance with 0.38 TFLOPS in its class.

FLOPS Comparison

GPU Type: integrated, Released in 2016

HD Graphics 630
Average
Max
GPU BASE CLOCK SPEED

GPU Base Clock is the standard operating frequency of a GPU, with variations in different models. It sets the performance baseline and can dynamically adjust for better performance in modern GPUs.

Base Clock

GPU Type: integrated, Released in 2016

HD Graphics 630
Average
Max
GPU BOOST CLOCK SPEED

GPU Boost Clock Speed is the GPU's ability to automatically increase its clock speed for better performance, especially in graphics-intensive tasks like gaming. It responds to factors like temperature and power consumption to optimize performance.

Boost Clock

GPU Type: integrated, Released in 2016

HD Graphics 630
Average
Max
THERMAL DESIGN POWER (TDP)

GPU Thermal Design Power (TDP) represents the maximum heat output of a graphics processing unit (GPU) under design conditions. It is measured in watts and determines the GPU's temperature control and cooling requirements.

The TDP of the HD Graphics 630 is close to the maximum, indicating the need for an effective cooling system to dissipate the excess heat generated by the GPU and prevent overheating issues.

Thermal Design Performance (TDP)

GPU Type: integrated, Released in 2016

HD Graphics 630
Average
Max

GPU SPECS TABLE

GENERAL
Brand Intel
Launch Date Aug 30th, 2016
Generation HD Graphics (Kaby Lake)
Type Integrated
Bus Interface Ring Bus
Chipset Specifications
Processor
Architecture Generation 9.5
Code Name Kaby Lake GT2
Foundry Intel
Manufacturing Technology 14 nm++
Number of Transistors unknown
Base Frequency 350 MHz
Boost Frequency 1000 MHz
Memory
Memory Size System Shared
Memory Type System Shared
Memory Frequency System Shared
Bandwith System Dependent
Bus System Shared
Performance
Pixel Rate 3.000 GPixel/s
Texture Rate 24.00 GTexel/s
FP16 Half 768.0 GFLOPS (2:1)
FP32 Float 384.0 GFLOPS
FP64 Double 96.00 GFLOPS (1:4)
Render Features
Shading Units 192
TMUs 24
ROPs 3
Execution Units 24
Board Design
Slot Width IGP
TDP 15 W
Outputs Motherboard Dependent
Graphic Features
DirectX 12 (12_1)
OpenGL 4.6
OpenCL 3.0
Vulkan 1.3
Shader Model 6.4
