GPUDecision

Radeon Graphics 128SP Review


Select a GPU to Compare

Add a GPU for comparison

Main Features

  • Launched in 2022
  • Base Frequency: 400 MHz
  • Boost Frequency: 2200 MHz
  • Memory Size: System Shared
  • Memory Type: System Shared
  • Fabrication Process: 5 nm

Radeon Graphics 128SP Overview

Radeon Graphics 128SP Radeon Graphics 128S...

The Radeon Graphics 128SP is a Integrated solution by AMD, launched in Sep 27th, 2022. Built on the 5 nm process, and based on the Raphael graphics processor, the device supports Direct X: 12 Ultimate . This ensures that all modern games will run on Radeon Graphics 128SP. It features 400 MHz base clock and can be boosted up to 2200 MHz. With a power draw rated at 15 W maximum, it is connected to the system using a PCIe 4.0 x8 interface.

Radeon Graphics 128SP is a member of AMD's Navi II IGP (Raphael) series of GPUs. Below you can find the latest models from this series.

AMD Navi II IGP (Raphael) Series History
Model Release Date Fabrication Process Performance
Radeon Graphics 128SP
September 2022 5 nm 563.2 GFLOPS

PERFORMANCE

FLOPS

FLOPS is commonly used for measuring GPU performance in 32-bit floating-point operations, essential for scientific computing, data analysis, machine learning, and graphics tasks. A higher value indicates faster and more complex calculations, vital for scientific research, simulations, and high-performance computing.

Radeon Graphics 128SP performs above average with 0.56 TFLOPS provides more performance overall GPU's in its class.

FLOPS Comparison

GPU Type: integrated, Released in 2022

Radeon Graphics 128SP
Average
Max
GPU BASE CLOCK SPEED

GPU Base Clock is the standard operating frequency of a GPU, with variations in different models. It sets the performance baseline and can dynamically adjust for better performance in modern GPUs.

Base Clock

GPU Type: integrated, Released in 2022

Radeon Graphics 128SP
Average
Max
GPU BOOST CLOCK SPEED

GPU Boost Clock Speed is the GPU's ability to automatically increase its clock speed for better performance, especially in graphics-intensive tasks like gaming. It responds to factors like temperature and power consumption to optimize performance.

Boost Clock

GPU Type: integrated, Released in 2022

Radeon Graphics 128SP
Average
Max
THERMAL DESIGN POWER (TDP)

GPU Thermal Design Power (TDP) represents the maximum heat output of a graphics processing unit (GPU) under design conditions. It is measured in watts and determines the GPU's temperature control and cooling requirements.

The TDP of the Radeon Graphics 128SP is close to the maximum, indicating the need for an effective cooling system to dissipate the excess heat generated by the GPU and prevent overheating issues.

Thermal Design Performance (TDP)

GPU Type: integrated, Released in 2022

Radeon Graphics 128SP
Average
Max

GPU SPECS TABLE

GENERAL
Brand AMD
Launch Date Sep 27th, 2022
Generation Navi II IGP (Raphael)
Type Integrated
Bus Interface PCIe 4.0 x8
Chipset Specifications
Processor
Architecture RDNA 2.0
Code Name Raphael
Foundry TSMC
Manufacturing Technology 5 nm
Number of Transistors 3,400 million
Transistor Density 12.9M / mm²
Chip Die Size 264 mm²
Chip Package Size LGA-1718
Base Frequency 400 MHz
Boost Frequency 2200 MHz
Memory
Memory Size System Shared
Memory Type System Shared
Memory Frequency System Shared
Bandwith System Dependent
Bus System Shared
Performance
Pixel Rate 8.800 GPixel/s
Texture Rate 17.60 GTexel/s
FP16 Half 1,126 GFLOPS (2:1)
FP32 Float 563.2 GFLOPS
FP64 Double 35.20 GFLOPS (1:16)
Render Features
Shading Units 128
TMUs 8
ROPs 4
Compute Units 2
Compute Units 2
L0 Cache 32 KB per WGP
L1 Cache 128 KB per Array
L2 Cache 2 MB
Board Design
Slot Width IGP
TDP 15 W
Outputs Motherboard Dependent
Power Connectors None
Graphic Features
DirectX 12 Ultimate (12_2)
OpenGL 4.6
OpenCL 2.0
Vulkan 1.3
Shader Model 6.7
Report a correction
