HD Graphics 630 vs HD Graphics 610 Comparison Overview
HD Graphics 630 HD Graphics 630
HD Graphics 610 HD Graphics 610
HD Graphics 630
HD Graphics 610

In this review, we will be comparing HD Graphics 630 and HD Graphics 610, two GPUs by Intel. HD Graphics 630 was introduced to market in August and was launched in August . Both HD Graphics 630 and HD Graphics 610 were launched within the same month so we are expecting this to be a fair comparison regarding age and available technology level.

HD Graphics 630 and HD Graphics 610 are members of Intel's HD Graphics (Kaby Lake) series of GPUs. Below you can find the latest models from this series.

Intel HD Graphics (Kaby Lake) Series History
Model Release Date Fabrication Process Performance
HD Graphics 610
August 2016 14 nm++ 201.6 GFLOPS
HD Graphics 630
August 2016 14 nm++ 384.0 GFLOPS

Here is a brief look at the main features of HD Graphics 630 and HD Graphics 610 before getting into our more detailed comparison.

HD Graphics 630 Key Specs

  • Launched in Aug 30th, 2016
  • Brand: Intel
  • GPU: Kaby Lake GT2
  • Tecnology: 14 nm++
  • Clock: 350 MHz
  • System Shared Ram
  • Mem. Clock: System Shared

HD Graphics 610 Key Specs

  • Launched in Aug 30th, 2016
  • Brand: Intel
  • GPU: Kaby Lake GT1
  • Tecnology: 14 nm++
  • Clock: 350 MHz
  • System Shared Ram
  • Mem. Clock: System Shared

Let's read on the following sections in order to better understand in detail how and compares and decide which one is better for you.

**This post contains affiliate links and I will be compensated if you make a purchase after clicking through my links. As an Amazon Associate I earn from qualifying purchases.

Reasons to choose HD Graphics 630 over HD Graphics 610
Render Config Shading Units (RCSU)
192 vs 96 Better Visual Effects Performance
Texture Mapping Units (TMU)
24 vs 12 Better Texture Performance
Ray Tracing (RT) Cores
3 vs 2 Better 3D Performance
Pixel Rate
3.000 GPixel/s vs 2.100 GPixel/s Better Pixel Rate
Texture Rate
24.00 GTexel/s vs 12.60 GTexel/s Better Texture Performance
Performance
384.0 GFLOPS vs 201.6 GFLOPS More processing power
Reasons to choose HD Graphics 610 over HD Graphics 630
GPU Boost Clock
1050 MHz vs 1000 MHz 50 MHz faster Boost Clock
Thermal Design Power (TDP)
5 W vs 15 W Requires less cooling

Common Strengths of HD Graphics 630 and HD Graphics 610
TDP
15 W vs 5 W Good Thermal Performance
Common Weaknesses of HD Graphics 630 and HD Graphics 610
Launch Dates
2016-08-30 vs 2016-08-30 GPUs are older than 1 year
Process Size
14 nm++ vs 14 nm++ Process thickness is not the latest
GPU Clock Speeds
350 MHz vs 350 MHz Below the average in this year

PERFORMANCE

FLOPS

FLOPS is commonly used for measuring GPU performance in 32-bit floating-point operations, essential for scientific computing, data analysis, machine learning, and graphics tasks. A higher value indicates faster and more complex calculations, vital for scientific research, simulations, and high-performance computing.

HD Graphics 630 has nearly top performance with 0.38 TFLOPS in its class.

HD Graphics 610 has nearly top performance with 0.20 TFLOPS in its class.

FLOPS Comparison (TFLOPS)

integrated type GPUs

HD Graphics 630
HD Graphics 610
Min
Average
Max
GPU BASE and BOOST CLOCK SPEED

The GPU base clock speed is the standard operating frequency, while the boost clock speed represents the maximum dynamic frequency the GPU can achieve under increased demand. These clock speeds influence the GPU's performance, with the base clock setting the standard level and the boost clock allowing for extra power when needed, enhancing overall responsiveness in demanding applications like gaming.

Base Clock Comparison (MHz)

integrated type GPUs

HD Graphics 630
HD Graphics 610
Min
Average
Max
Boost Clock Comparison (MHz)

integrated type GPUs

HD Graphics 630
HD Graphics 610
Min
Average
Max
MEMORY SIZE and MEMORY CLOCK SPEED

GPU memory size refers to the storage capacity for visual data. This capacity is crucial for tasks like gaming and graphic-intensive work. Memory clock speed affects how quickly the GPU's memory operates. Faster memory speed improves performance, especially in high-resolution gaming. Balancing memory size and clock speed is vital for a GPU's graphics handling capabilities..

The memory of both HD Graphics 630 and HD Graphics 610 are system-shared, which means that memory-based performance values depend on the system.
GPU THERMAL DESIGN POWER (TDP)

GPU TDP, or Thermal Design Power, quantifies the maximum heat a graphics processing unit (GPU) generates under load. It's vital for selecting appropriate cooling solutions and power efficiency. Higher TDP GPUs require better cooling, while lower TDP GPUs are more power-efficient. Understanding TDP aids in choosing the right GPU for a system.

HD Graphics 630 has nearly highest TDP with 15.00 W in its class.

HD Graphics 610 has nearly highest TDP with 5.00 W in its class.

TDP Comparison (Watts)

integrated type GPUs

HD Graphics 630
HD Graphics 610
Min
Average
Max
HD Graphics 630 vs HD Graphics 610: Specs Comparison Table

In this section, we will be comparing the specifications the HD Graphics 630 and the HD Graphics 610.

Processor
Model HD Graphics 630 HD Graphics 610
Generation HD Graphics (Kaby Lake) HD Graphics (Kaby Lake)
Release Date 2016-08-30 2016-08-30
Brand Intel Intel
GPU Name Kaby Lake GT2 Kaby Lake GT1
Architecture Generation 9.5 Generation 9.5
Foundry Intel Intel
Process Size 14 nm++ 14 nm++
Number of Transistors unknown unknown
IGP Variants Pentium G4600: 1100 MHz , Core i3-7100: 1100 MHz , Core i3-7350K: 1150 MHz , Core i5-7400: 1000 MHz , Core i5-7500T: 1100 MHz , Core i5-7500: 1100 MHz , Core i5-7600: 1150 MHz , Core i5-7600K: 1150 MHz , Core i7-7700T: 1150 MHz , Core i7-7700: 1150 MHz , Celeron G3930: 1050 MHz , Pentium G4560T: 1050 MHz , Pentium G4560: 1050 MHz
GPU Base Clock Speed 350 MHz 350 MHz
GPU Clock Speed 1000 MHz 1050 MHz
Memory
Memory System Shared System Shared
Memory Type System Shared System Shared
Memory Frequency System Shared z System Shared z
Memory Bus System Shared System Shared
Memory Bandwith System Dependent System Dependent
Bus Interface Ring Bus Ring Bus
Render Configurations
Shading Units 192 96
TMUs 24 12
ROPs 3 2
Execution Units 24 12
Performance and Features
Pixel Rate 3.000 GPixel/s 2.100 GPixel/s
Texture Rate 24.00 GTexel/s 12.60 GTexel/s
DirectX 12 12
OpenGL 4.6 4.6
OpenCL 3.0 3.0
Vulkan 1.3 1.3
Shader Model 6.4 6.4
FP16 Half 768.0 GFLOPS (2:1) 403.2 GFLOPS (2:1)
FP32 384.0 GFLOPS 201.6 GFLOPS
FP64 double 96.00 GFLOPS (1:4) 50.40 GFLOPS (1:4)
OTHER
Slot Width IGP IGP
TDP 15 W 5 W
Outputs Motherboard Dependent Motherboard Dependent
