GPUDecision

T1000 Review


Select a GPU to Compare

Add a GPU for comparison

Main Features

  • Launched in 2021
  • Base Frequency: 1065 MHz
  • Boost Frequency: 1395 MHz
  • Memory Size: 4 GB
  • Memory Type: GDDR6
  • Fabrication Process: 12 nm
CHECK PRICE
CHECK PRICE

T1000 Overview

T1000 T1000
See at AMAZON

The T1000 is a Dedicated solution by NVIDIA, launched in May 6th, 2021. Built on the 12 nm process, and based on the TU117 graphics processor, the device supports Direct X: 12 . This ensures that all modern games will run on T1000. It features 1065 MHz base clock and can be boosted up to 1395 MHz. With a power draw rated at 50 W maximum, it is connected to the system using a PCIe 3.0 x16 interface.

T1000 is a member of NVIDIA's Quadro Turing (Tx000) series of GPUs. Below you can find the latest models from this series.

NVIDIA Quadro Turing (Tx000) Series History
Model Release Date Fabrication Process Performance
T1000
May 2021 12 nm 2.500 TFLOPS
T1000 8 GB
Compare
May 2021 12 nm 2.500 TFLOPS
T400
Compare
May 2021 12 nm 1,094 GFLOPS
T400 4 GB
Compare
May 2021 12 nm 1,094 GFLOPS
T600
Compare
April 2021 12 nm 1.709 TFLOPS
Quadro RTX 4000
Compare
November 2018 12 nm 7.119 TFLOPS
Quadro RTX 5000
Compare
August 2018 12 nm 11.15 TFLOPS
Quadro RTX 6000
Compare
August 2018 12 nm 16.31 TFLOPS

PERFORMANCE

FLOPS

FLOPS is commonly used for measuring GPU performance in 32-bit floating-point operations, essential for scientific computing, data analysis, machine learning, and graphics tasks. A higher value indicates faster and more complex calculations, vital for scientific research, simulations, and high-performance computing.

FLOPS Comparison

GPU Type: non-mobile, Released in 2021

Average
Max
GPU BASE CLOCK SPEED

GPU Base Clock is the standard operating frequency of a GPU, with variations in different models. It sets the performance baseline and can dynamically adjust for better performance in modern GPUs.

The base clock speed of the T1000 is below average, which could be a sign of lower performance potential.
Base Clock

GPU Type: non-mobile, Released in 2021

T1000
Average
Max
GPU BOOST CLOCK SPEED

GPU Boost Clock Speed is the GPU's ability to automatically increase its clock speed for better performance, especially in graphics-intensive tasks like gaming. It responds to factors like temperature and power consumption to optimize performance.

Boost Clock

GPU Type: non-mobile, Released in 2021

T1000
Average
Max
MEMORY SIZE

GPU "Memory Size" is essential for high-performance gaming and complex graphics tasks. It affects performance, frame rates, and multi-monitor support.

The Memory amount of T1000 is 4 GB .

Memory Size

GPU Type: non-mobile, Released in 2021

Average
Max
MEMORY CLOCK SPEED

"Memory Clock Speed" in GPUs controls VRAM speed, impacting data access and graphics performance. Higher speeds enhance data handling, benefiting high-resolution gaming, but memory type and bandwidth also influence overall GPU performance.

Memory Clock

GPU Type: non-mobile, Released in 2021

T1000
Average
Max
THERMAL DESIGN POWER (TDP)

GPU Thermal Design Power (TDP) represents the maximum heat output of a graphics processing unit (GPU) under design conditions. It is measured in watts and determines the GPU's temperature control and cooling requirements.

The TDP of the T1000

Thermal Design Performance (TDP)

GPU Type: non-mobile, Released in 2021

Average
Max

GPU SPECS TABLE

GENERAL
Brand NVIDIA
Launch Date May 6th, 2021
Generation Quadro Turing (Tx000)
Type Dedicated
Bus Interface PCIe 3.0 x16
Chipset Specifications
Processor
Architecture Turing
Code Name TU117
Foundry TSMC
Manufacturing Technology 12 nm
Number of Transistors 4,700 million
Transistor Density 23.5M / mm²
Chip Die Size 200 mm²
Chip Package Size BGA-960
Base Frequency 1065 MHz
Boost Frequency 1395 MHz
Memory
Memory Size 4 GB
Memory Type GDDR6
Memory Frequency 1250 MHz 10 Gbps effective
Bandwith 160.0 GB/s
Bus 128 bit
Performance
Pixel Rate 44.64 GPixel/s
Texture Rate 78.12 GTexel/s
FP16 Half 5.000 TFLOPS (2:1)
FP32 Float 2.500 TFLOPS
FP64 Double 78.12 GFLOPS (1:32)
Render Features
Shading Units 896
TMUs 56
ROPs 32
L1 Cache 64 KB (per SM)
L2 Cache 1024 KB
SM Count 14
Board Design
Slot Width Single-slot
TDP 50 W
Outputs 4x mini-DisplayPort 1.4a
Power Connectors None
Suggested Power Supply 250 W
Board Number PG172 SKU 500
Graphic Features
DirectX 12 (12_1)
OpenGL 4.6
OpenCL 3.0
Vulkan 1.3
Shader Model 6.7
CUDA 7.5
Report a correction
