Radeon RX 7800 XT vs Radeon RX 7700 Comparison Overview
Radeon RX 7800 XT Radeon RX 7800 XT
See at AMAZON
Radeon RX 7700 Radeon RX 7700
See at AMAZON
Radeon RX 7800 XT
See at AMAZON
Radeon RX 7700
See at AMAZON

In this review, we will be comparing Radeon RX 7800 XT and Radeon RX 7700, two GPUs by AMD. Radeon RX 7800 XT was introduced to market in August and was launched in January . There is only 8 months difference between Radeon RX 7800 XT and Radeon RX 7700 so we are expecting this to be a fair comparison regarding age and technology level.

Radeon RX 7800 XT and Radeon RX 7700 are members of AMD's Navi III (RX 7000) series of GPUs. Below you can find the latest models from this series.

AMD Navi III (RX 7000) Series History
Model Release Date Fabrication Process Performance
Radeon RX 7500 XT
  Compare
May 2025 6 nm 9.421 TFLOPS
Radeon RX 7600
  Compare
May 2023 6 nm 21.75 TFLOPS
Radeon RX 7700
May 2025 5 nm 31.95 TFLOPS
Radeon RX 7700 XT
  Compare
August 2023 5 nm 35.17 TFLOPS
Radeon RX 7800 XT
August 2023 5 nm 37.32 TFLOPS
Radeon RX 7900 GRE
  Compare
July 2023 5 nm 45.98 TFLOPS
Radeon RX 7990 XTX
  Compare
January 1970 5 nm 88.45 TFLOPS
Radeon RX 7900 XT
  Compare
November 2022 5 nm 51.48 TFLOPS

Here is a brief look at the main features of Radeon RX 7800 XT and Radeon RX 7700 before getting into our more detailed comparison.

Radeon RX 7800 XT Key Specs

  • Launched in Aug 25th, 2023
  • Brand: AMD
  • GPU: Navi 32
  • Tecnology: 5 nm
  • Clock: 1295 MHz
  • 16 GB Ram
  • Mem. Clock: 2425 MHz 19.4 Gbps effective

Radeon RX 7700 Key Specs

  • Launched in 2023
  • Brand: AMD
  • GPU: Navi 32
  • Tecnology: 5 nm
  • Clock: 1900 MHz
  • 12 GB Ram
  • Mem. Clock: 2250 MHz 18 Gbps effective

Let's read on the following sections in order to better understand in detail how and compares and decide which one is better for you.

**This post contains affiliate links and I will be compensated if you make a purchase after clicking through my links. As an Amazon Associate I earn from qualifying purchases.

Reasons to choose Radeon RX 7800 XT over Radeon RX 7700
Memory Size
16 GB vs 12 GB 4 GB more RAM
Memory Clock
2425 MHz vs 2250 MHz 175 MHz faster Memory Clock
Memory Bus Bits
256 bit vs 192 bit More Memory Bits
Memory Bandwidth
620.8 GB/s vs 432.0 GB/s Wider Memory Bandwith
Render Config Shading Units (RCSU)
3840 vs 3072 Better Visual Effects Performance
Texture Mapping Units (TMU)
240 vs 192 Better Texture Performance
Raster Operations Pipeline (ROP)
60 vs 48 Better Optical Effects Performance
L2 Cache Memory
4 MB vs 2 MB More Cache Memory
Texture Rate
583.2 GTexel/s vs 499.2 GTexel/s Better Texture Performance
Performance
37.32 TFLOPS vs 31.95 TFLOPS More processing power
Reasons to choose Radeon RX 7700 over Radeon RX 7800 XT
GPU Base Clock
1900 MHz vs 1295 MHz 605 MHz faster Base Clock
GPU Boost Clock
2600 MHz vs 2430 MHz 170 MHz faster Boost Clock
Thermal Design Power (TDP)
200 W vs 263 W Requires less cooling
Pixel Rate
249.6 GPixel/s vs 233.3 GPixel/s Better Pixel Rate

Common Strengths of Radeon RX 7800 XT and Radeon RX 7700
Process Size
5 nm vs 5 nm Latest Process Technology
Memory Size
16 GB vs 12 GB Both GPUs have more than 4 GB Memory
Memory Clock Speeds
2425 MHz vs 2250 MHz Over Average Memory Clock Speeds
Bus Interface
PCIe 4.0 x16 vs PCIe 4.0 x16 Both have latest Bus type
Common Weaknesses of Radeon RX 7800 XT and Radeon RX 7700
Launch Dates
2023-08-25 vs 2023-01-01 GPUs are older than 1 year
TDP
263 W vs 200 W May face thermal performance problems

PERFORMANCE

FLOPS

FLOPS is commonly used for measuring GPU performance in 32-bit floating-point operations, essential for scientific computing, data analysis, machine learning, and graphics tasks. A higher value indicates faster and more complex calculations, vital for scientific research, simulations, and high-performance computing.

Radeon RX 7800 XT performs above average with 37.32 TFLOPS provides more performance overall GPU's in its class.

FLOPS Comparison (TFLOPS)

non-mobile type GPUs

Radeon RX 7800 XT
Radeon RX 7700
Min
Average
Max
GPU BASE and BOOST CLOCK SPEED

The GPU base clock speed is the standard operating frequency, while the boost clock speed represents the maximum dynamic frequency the GPU can achieve under increased demand. These clock speeds influence the GPU's performance, with the base clock setting the standard level and the boost clock allowing for extra power when needed, enhancing overall responsiveness in demanding applications like gaming.

The base clock speed of the Radeon RX 7800 XT is below average, which could be a sign of lower performance potential.
Base Clock Comparison (MHz)

non-mobile type GPUs

Radeon RX 7800 XT
Radeon RX 7700
Min
Average
Max
Boost Clock Comparison (MHz)

non-mobile type GPUs

Radeon RX 7800 XT
Radeon RX 7700
Min
Average
Max
MEMORY SIZE and MEMORY CLOCK SPEED

GPU memory size refers to the storage capacity for visual data. This capacity is crucial for tasks like gaming and graphic-intensive work. Memory clock speed affects how quickly the GPU's memory operates. Faster memory speed improves performance, especially in high-resolution gaming. Balancing memory size and clock speed is vital for a GPU's graphics handling capabilities..

The base clock speed of the Radeon RX 7800 XT is below average, which could be a sign of lower performance potential. The base clock speed of the Radeon RX 7700 is below average, you may evaluate it further for your decision.
Memory Size Comparison (GB)

non-mobile type GPUs

Radeon RX 7800 XT
Radeon RX 7700
Min
Average
Max
Memory Clock Comparison (MHz)

non-mobile type GPUs

Radeon RX 7800 XT
Radeon RX 7700
Min
Average
Max
GPU THERMAL DESIGN POWER (TDP)

GPU TDP, or Thermal Design Power, quantifies the maximum heat a graphics processing unit (GPU) generates under load. It's vital for selecting appropriate cooling solutions and power efficiency. Higher TDP GPUs require better cooling, while lower TDP GPUs are more power-efficient. Understanding TDP aids in choosing the right GPU for a system.

Radeon RX 7800 XT better than average with 263.00 W TDP in its class.

Radeon RX 7700 better than average with 200.00 W TDP in its class.

TDP Comparison (Watts)

non-mobile type GPUs

Radeon RX 7800 XT
Radeon RX 7700
Min
Average
Max
Radeon RX 7800 XT vs Radeon RX 7700: Specs Comparison Table

In this section, we will be comparing the specifications the Radeon RX 7800 XT and the Radeon RX 7700.

Processor
Model Radeon RX 7800 XT Radeon RX 7700
Generation Navi III (RX 7000) Navi III (RX 7000)
Predecessor Navi II Navi II
Release Date 2023-08-25 2023-01-01
Brand AMD AMD
GPU Name Navi 32 Navi 32
Architecture RDNA 3.0 RDNA 3.0
Foundry TSMC TSMC
Process Size 5 nm 5 nm
Number of Transistors 28,100 million 28,100 million
Density of Transistors 81.2M / mm² 81.2M / mm²
Die Size 346 mm² 346 mm²
Package MCM MCM
GPU Variant Navi 32 XT (215-180000006) Navi 32
GPU Base Clock Speed 1295 MHz 1900 MHz
GPU Clock Speed 2430 MHz 2600 MHz
Game Clock Speed 2124 MHz 2400 MHz
Memory
Memory 16 GB 12 GB
Memory Type GDDR6 GDDR6
Memory Frequency 2425 MHz 2250 MHz
Memory Bus 256 bit 192 bit
Memory Bandwith 620.8 GB/s 432.0 GB/s
Bus Interface PCIe 4.0 x16 PCIe 4.0 x16
Render Configurations
Shading Units 3840 3072
TMUs 240 192
ROPs 96 96
Config Units 60 48
RT Cores 60 48
L0 Cache 32 KB per WGP 32 KB per WGP
L1 Cache 128 KB per Array 128 KB per Array
L2 Cache 4 MB 2 MB
L3 Cache 64 MB 64 MB
Performance and Features
Pixel Rate 233.3 GPixel/s 249.6 GPixel/s
Texture Rate 583.2 GTexel/s 499.2 GTexel/s
DirectX 12 Ultimate 12 Ultimate
OpenGL 4.6 4.6
OpenCL 2.2 2.2
Vulkan 1.3 1.3
Shader Model 6.7 6.7
FP16 Half 74.65 TFLOPS (2:1) 63.90 TFLOPS (2:1)
FP32 37.32 TFLOPS 31.95 TFLOPS
FP64 double 1,166 GFLOPS (1:32) 998.4 GFLOPS (1:32)
OTHER
Length 267 mm 10.5 inches 267 mm 10.5 inches
Width 111 mm 4.4 inches 135 mm 5.3 inches
Height 50 mm 2 inches 50 mm 2 inches
Suggested Power Supply 600 W 550 W
Slot Width Dual-slot Dual-slot
TDP 263 W 200 W
Outputs 1x HDMI 2.1a3x DisplayPort 2.1 1x HDMI 2.1a2x DisplayPort 2.11x USB Type-C
Power Connectors 2x 8-pin 1x 8-pin
